TECHNICAL SHEET JCB
Wheel loader JCB TM 220 1

JCB

Main characteristics

Model Tm 220
Type of vehicle Wheel loader
Poids opérationnel 6,495 t
Engine power 55 kw
Bucket capacity 0,87 m³
Used JCB loader
Wheel loader JCB TM 220

Technical data

  Flèche monobloc
Technical characteristics
Machine weight 6,495 t
Tyres dimensions 405/70 R20 SPT9
Shoe width -
Overall height -
Overall length -
Bucket width 2 m
Dimensions and weights
Pendulum length -
Max. digging depth -
Bucket capacity 0,83 m³
Length for transport 5.998 m
Transport width 1.902 m
Transport height 2.634 m
External turning radius 4.755 m
Maximum dumping height 3.637 m
Speed 20 km/h
Engines
Engine manufacturer Kohler
Engine type KDI 2504 TCR
Engine power 55 kW
Engine power 2.482 l
Tours/minutes 1500 rpm
Maximum torque 300 Nm
Number of cylinders 4
Bore × stroke -
Emission level Stufe III B

Ads JCB loader

Key
  • : Standard equipment
  • : Equipments in option

Notes :

1 The information and pictures of this technical sheet are given on an indicative basis. All these data may be modified by the manufacturer. For more information, you can directly go to your dealership.

2 : Working weight including specific work equipments, with a 2.6m arm, 0.65 m3 bucket, lubricant, coolant, full fuel tank and standard equipments included.
