TECHNICAL SHEET Hitachi
Pelle hydraulique Hitachi ZX 490 LCH 6 ¹

Main characteristics

Model	zx 490 lch 6
Type of vehicle	Pelle hydraulique
Poids opérationnel	49,4 t
Engine power	270 kw
Bucket capacity	2,1 m³

	Flèche monobloc
Technical characteristics
Machine weight	49,4 t
Length for transport	12,01 m
Transport width	3,82 m
Transport height	3,53 m
Dimensions and weights
Pendulum length	-
Max. digging depth	-
Bucket capacity	2,1 m³
Track width	600 mm
Boom type	Monobloc
Maximum range	11,84 m
Dredging depth	7,77 m
Engines
Engine manufacturer	Isuzu
Engine type	AQ 6 UZ 1 X
Engine power	270 kW
Engine power	9,839 l
Tours/minutes	1500 t/min
Maximum torque	1435 Nm
Number of cylinders	6
Bore × stroke	120 × 145 mm
Emission level	IV

Key

: Standard equipment
: Equipments in option

Notes :

¹ The information and pictures of this technical sheet are given on an indicative basis. All these data may be modified by the manufacturer. For more information, you can directly go to your dealership.

²: Working weight including specific work equipments, with a 2.6m arm, 0.65 m3 bucket, lubricant, coolant, full fuel tank and standard equipments included.
