TECHNICAL SHEET Liebherr
Wheel loader Liebherr L 586 1
Main characteristics
| Model | L 586 |
| Type of vehicle | Wheel loader |
| Poids opérationnel | 31,4 t |
| Engine power | 250 kw |
| Bucket capacity | 5,5 m³ |
Technical data
| Flèche monobloc | |
| Technical characteristics | |
| Machine weight | 31,4 t |
| Tyres dimensions | 29.5 R 25 |
| Shoe width | - |
| Overall height | - |
| Overall length | - |
| Bucket width | 3,4 m |
| Dimensions and weights | |
| Pendulum length | - |
| Max. digging depth | - |
| Bucket capacity | 5,5 m³ |
| Length for transport | 9,9 m |
| Transport width | 3,4 m |
| Transport height | 3,74 m |
| External turning radius | 8,25 m |
| Maximum dumping height | 3,31 m |
| Speed | 35 km/h |
| Engines | |
| Engine manufacturer | Liebherr |
| Engine type | D 936 LA 6 |
| Engine power | 250 kW |
| Engine power | 10,52 l |
| Tours/minutes | 1500 rpm |
| Maximum torque | - |
| Number of cylinders | - |
| Bore × stroke | - |
| Emission level | III A |
Key
- : Standard equipment
Notes :
1 The information and pictures of this technical sheet are given on an indicative basis. All these data may be modified by the manufacturer. For more information, you can directly go to your dealership.
2 : Working weight including specific work equipments, with a 2.6m arm, 0.65 m3 bucket, lubricant, coolant, full fuel tank and standard equipments included.
